Fix Hybrid Network Performance Issues

Measure from where the user sits, not from the data centre. Run synthetic transactions that replay the real user journey from each site continuously, then break the result into DNS time, connect time, TLS handshake and server response. An end-to-end number tells you something is slow; the breakdown tells you which hop owns it.

On a flat on-premises network bandwidth is effectively free and nobody measures it. The moment an application moves to cloud, every request competes for a finite, paid, shared link — and TCP behaves very differently at 40 ms of round-trip time than at 1 ms. The same application, unchanged, moves a fraction of the data per second. Throughput is the number that tells you whether the path can carry what you put on it.

Sometimes, but not by default. A dedicated circuit to a cloud provider usually cuts latency and, more importantly, cuts jitter compared with traffic crossing the public internet. But hybrid connectivity adds hops and encryption overhead, so a badly designed hybrid path can be slower than the internet path it replaced. The gain is predictability, not raw speed.

Hybrid connectivity, the backbone of Hybrid Infrastructure, means running multiple transport types at once and using all of them. Failover means holding a backup idle until the primary breaks. Hybrid is a steady-state design decision about capacity and path selection; failover is a resilience mechanism that activates on fault. A hybrid design can include failover, but the two solve different problems.”

Collect locally and summarise before you transmit. Put a collector at the low-bandwidth site so polling and flow collection happen on the LAN, then send only aggregated metrics upstream — a few kilobits per second rather than a continuous stream. Set the polling interval by what you need to see, and never export raw flow across the link you are trying to protect.

Because SD-WAN changes the path underneath you. Policy moves sessions between MPLS, broadband and LTE according to conditions, so an average measured across all underlays describes a path no packet ever took. Measuring each underlay separately, and logging every path-selection event, is the only way to answer why performance changed at a specific moment.

Continuous collection is the easy half; the hard half is who reads it at 3am. Baseline-driven alerting cuts overnight noise to events that genuinely deviate from normal for that hour and that day. Beyond that it is an operational choice: an in-house on-call rota, or a managed team that triages and escalates only real incidents.
